INCH-POUND
MIL-DTL-52286/6A
18 May 2010
SUPERSEDING
MIL-C-52286/6
4 May 1970
DETAIL SPECIFICATION SHEET
CABLE ASSEMBLY, POWER, ELECTRICAL
Inactive for new design after 9 December 2003.
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and MIL-DTL-52286, "Cable Assemblies, Power, Electrical (with Molded on
Terminations)".
FIGURE 1. Cable assembly, power, electrical.
REQUIREMENTS:
Dimensions and configurations shall be in accordance with figure 1 and the MIL-DTL-52286
figures as specified.
Connector A shall be in accordance with figure 11 of MIL-DTL-52286.
Connector B shall be in accordance with figure 13 of MIL-DTL-52286.
AMSC N/A
FSC 6150
