MIL-DTL-52286/3C
Connector A shall be in accordance with figure 2 of MIL-DTL-52286.
Cable hanger B shall be in accordance with figure 7 of MIL-DTL-52286.
Cable C shall be in accordance with table I.
TABLE 1. Cable assemblies.
Dash no.
Length in feet
Cable
-1
10
CO-02 LLF (2/16) 0345
-2
25
CO-02 LLF (2/16) 0345
Minimum bond between connectors and cables: 70 pounds.
The part or identifying number (PIN) to be used for cable assemblies acquired to this
specification is created as follows:
M 52286/3 - X
Dash number (see table I)
Specification sheet number
M prefix
Example of reference part number: M52286/3-1
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
Custodians:
Preparing Activity:
Army - CR4
DLA - GS8
DLA - GS
(Project 6150-2010-005)
Review Activity:
Army - AT
NOTE: The activities listed above were interested in this document as of the date of this
document. Since organizations and responsibilities can change, you should verify the currency
of the information above using the ASSIST database at https://assist.daps.dla.mil/.
