MIL-DTL-52286/1C
REQUIREMENTS:
Dimensions and configurations shall be in accordance with figure 1 and the MIL-DTL-52286
figures as specified.
Connector A shall be in accordance with figure 3 of MIL-DTL-52286.
Connector B shall be in accordance with figure 2 of MIL-DTL-52286.
Connector C shall be in accordance with figure 4 of MIL-DTL-52286.
Cable hanger D shall be in accordance with figure 5 of MIL-DTL-52286.
Male dummy E shall be in accordance with figure 8 of MIL-DTL-52286.
Cable F shall be in accordance with table I.
TABLE I. Cable assemblies.
Dash no.
Cable
-1
C0-02 HLF (2/10) 0660
-2
C0-02 HLF (2/12) 0625
Minimum bond between connectors and cables: 70 pounds.
The part or identifying number (PIN) to be used for cable assemblies acquired to this
specification is created as follows:
M 52286/1 - X
Dash number (see table I)
Specification sheet number
M prefix
Example of reference part number: M52286/1-1
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
